Specification:

• PV Input:

Max. PV Power: 13.2KW
Max. Input Voltage: 500Vdc
Rated Input Voltage: 350Vdc
Start-up Voltage: 60Vdc
MPPT Voltage Range: 60-420Vdc
Max. Input Current: 20A/20A
Max. Short Circuit Current: 27A/27A
MPPT Number/Max. Input Strings Number: 2/2

• Battery Input/Output:

Battery Voltage Range: 40-60Vdc
Max. Battery Charge/Dischage Current: 140A/140A
Max. Battery Charge/Dischage Power: 7KW/7KW
Communication: RS485/CAN

• Inverter Output:

Rated Output Power: 6.6kW
Max. Apparent Output Power: 6.6kVA
Rated Output Current: 30A
EPS Switch Time: <10ms
Rated Output Voltage/Frequency: L/N/PE 22OV/23OV/24OV 5OHz/6OHz
Power Factor: 0.8leading…0.8lagging
THDi: <2%

• Grid Input:

Max.Input Power: 10KW
Max. Input Current: 50A
Frequency Range: 40-70Hz
Input Voltage: L/N/PE 220V/230V 50Hz/60Hz

• EPS Port:

Max. Output Power(Hybrid): 10KW
Max. Output Power(No Grid): 6.6KW
Max. Output Current(Hybrid): 50A
Max. Output Current(No Grid): 30A

• Smart Port:

Work Mode: Second Load/Generator Input
Max. Input/Output Power: 8KW
Max. Input/Output Current: 40A
Rated Voltage/Frequency: L/N/PE 220V/230V/240V 50Hz/60Hz

• System:

Display & Operate: 3.5′ LCD & Button
Max. Efficiency: 97.5%
International Protection Code: IP66
Amvient Temperature: -25°C~60°C (>45°Cderating)
Humidity: 0-100% (No Condensation)
Cooling Concept: Forced-air
Parallel: 12 units
Decibels: 45db
Inverter Main Size(L*W*H): 479*330*170mm (±2%) (Excluding Lugs and Terminals)
Inverter Net Weight: 13.5kG (±2%)
