Specification:

• INVERTER INPUT/OUTPUT (GRID):

Rated Power(kW): 16
Rated Voltage: 220 / 230 / 240 V a.c., L+N+PE
Rated Frequency (Hz): 50 / 60
Rated Factor Range: 0.8 Leading ~ 0.8 Lagging
Switch Time(ms): < 10
Current (Maximum Continuous) (A a.c.): 69.6
Max Output Overcurrent Protection: 100

• BATTERY:

Battery Type: Lithium / Lead-acid
Battery Voltage Range (V d.c.): 40 ~ 60
Rated Battery Voltage (V d.c.): 51.2
Max Charge Current (A d.c.): 275
Max Discharge Current (A d.c.): 275
Reverse Connect Protection: Yes

• PV INPUT:

No.of MPPT Tracker / Strings: 3 / 2+2+2
Max. PV Array Power: 22.5
Max. DC Voltage (V d.c.): 550
MPPT Voltage Range (V d.c.): 120~480
Start-Up Voltage (V d.c.): 120
Max. Input Current (A d.c.): 3*26
Isc PV (Absolute Maximum) (A d.c.): 3*29

• AC OUTPUT (EPS):

EPS Rated Output Voltage: 220 / 230 / 240 V a.c., L+N+PE
EPS Rated Output Frequency (Hz): 50 / 60
EPS Rated Output Active Power (kW): 16
EPS Rated Output Apparent Power (kVA): 16
EPS Rated Output Current (A a.c.): 69.6
Overload Capacity (Off Grid): 200% (,10s) / 150% ( <60s)

• Efficiency:

Max.Efficiency: 99.90%
Euro Efficiency: 96.50%
MPPT Efficiency: 97.30%

• PROTECTION & FEATURE:

Insulation Monitoring: Yes
Residual Current Monitoring: Yes
Parallel Function: Yes
Protection Degree: IP66
CertificationsIEC: 62109-1/2,IEC 62477-1,IEC 61000-6-1,IEC 61000-6-3 EN 50549-1&-10,NRS 097-2-1, ABNT NBR 16149,IEC 61727,IEC61683,IEC62116 etc.
Other Protection: Output Over Voltage, Output Over Current, Short Circuit, Surge, Temperature

• Dimension:

Machine Dimension (W*H*D) (mm): 600*466*252
